X-Tended Reach Grain Carts

X2431

Capacity: 23,8 t • 30,8 m³ | Auger Diameter: 45,7 cm | Unload Rate: 11,9 t/min

Harvest season rarely goes according to plan, but nothing is more dependable when it comes to getting the job done than the trusted line of J&M Front-Folding Corner Auger Carts.

The single auger design, rugged tank and undercarriage construction has been helping farmers hold more, travel faster and unload quicker for four decades, keeping them on the go even in the most extreme conditions.

Standard Features

Patented flow control spout with side shooter design
Heavy-duty bottom auger tube
Heavy-duty driveline and gearbox
Over-running, automatic cut-out clutch
Side mounted easy access ladder
Heavy-duty jack
Hydraulic sliding axle

Optional Features

Roll tarp
5-Point scale system
Multiple hitch options
Hydraulic or pneumatic brakes

SuperEdge Flighting Balanced Within 28 Grams

All J&M chaser bins feature thick flighting with a patented SuperEdge that puts more material where it is needed, on the outer edge. In addition, we reinforce the flighting at critical wear points to increase life and durability. All augers are balanced to within 28 grams. Precision manufacturing ensures a quiet running system that extends overall auger life and performance by reducing vibration to the drive system.

Specifications

	2431
Capacity	24 t
Auger Diameter	45,7 cm
Unload Rate	11,9 t/min
Wheels (2)	21×32, 27×32 or 30×32
Tires (2)	24.5×32, 30.5×32 or 900/60R32
Spindles (2)	11,4 cm (No Brakes) 12,7 cm (Brakes)
Tongue Weight Empty Loaded	1318 kg 2490 kg
Total Weight	6297 kg

DIMENSIONS

	2431
A	340 cm
B	290 cm
C	203 cm
D	246 cm
E	300 cm
F	305 cm
G	152 cm
H	584 cm
I	48 cm
J	612 cm
K	944 cm
L	437 cm
M	297 cm
N	671 cm
O	366 cm
P	46 cm
Q	41 cm
